Product Details
Place of Origin: Xi'an City, Shaanxi Province, China
Brand Name: DH
Certification: CE
Model Number: DKXM500
Payment & Shipping Terms
Minimum Order Quantity: 1
Payment Terms: T/T, Western Union
Model: |
DKXM500 Unpacking Machine |
Unboxing Speed（m/min）: |
10~15pcs/min |
Carton Size (Maximum Or Minimum Size Cannot Exist At The Same Time): |
Length（mm） 280-500 Width（mm）150-400 Height（mm）150-400（mm） |
Total Power （kw）: |
1.5 |
Air Pressure Source Supply (kgf/cm²): |
6kgf/cm² |
Machine Net Weight (kg): |
350 |
Machine Dimensions (length × Width × Height) (mm): |
2010×2000×1450 |
Power Supply Type: |
220V 50Hz |
Applicable Tape: |
W48;W60;W75(Choose One) |
Model: |
DKXM500 Unpacking Machine |
Unboxing Speed（m/min）: |
10~15pcs/min |
Carton Size (Maximum Or Minimum Size Cannot Exist At The Same Time): |
Length（mm） 280-500 Width（mm）150-400 Height（mm）150-400（mm） |
Total Power （kw）: |
1.5 |
Air Pressure Source Supply (kgf/cm²): |
6kgf/cm² |
Machine Net Weight (kg): |
350 |
Machine Dimensions (length × Width × Height) (mm): |
2010×2000×1450 |
Power Supply Type: |
220V 50Hz |
Applicable Tape: |
W48;W60;W75(Choose One) |
Keyword
1. Unpacking machine
2. Fully automatic unpacking equipment
3. Automatic carton opening machine
Feature
■This machine has a simple structure, is easy to operate and maintain, and is widely used in all walks of life.
■The open structure is adopted on both sides of the transport box, allowing the operator to have a better view and make the operation more convenient.
■Servo box picking and servo box pushing are stable and easy to adjust.
■Low noise, smooth use, and no damage to the carton.
■The container warehouse adopts a tilted unpowered container warehouse design, which can replenish cartons at any time without stopping the machine.
■It can achieve seamless connection with front-end and back-end equipment.
■The standard model is carbon steel spray-painted (frosted silver), which can be customized according to customer needs.
Specification
| model | DKXM500 Unpacking machine | |
| Unboxing speed(m/min) | 10~15pcs/min | |
|
Carton size (Maximum or minimum size cannot exist at the same time) |
length(mm) | 280-500 |
| Width(mm) | 150-400 | |
| height(mm) | 150-400 | |
| total power | (kw) | 1.5 |
| Air pressure source supply (kgf/cm²) | 6kgf/cm² | |
| Machine net weight (kg) | 350 | |
| Machine dimensions (length × width × height) (mm) | 2010×2000×1450 | |
| Power supply type | 220V 50Hz | |
| Applicable tape | W48;W60;W75(Choose one) | |
