Product Details
Place of Origin: Xi'an City, Shaanxi Province, China
Brand Name: DH
Certification: CE
Model Number: Online
Payment & Shipping Terms
Minimum Order Quantity: 10
Payment Terms: T/T, Western Union
Product Name: |
DOD Assembly Line Intelligent Large Font Inkjet Printer |
Bitmap Font: |
16 Point, 14 Point, 12 Point, 8 Point, 7 Point |
Number Of Nozzles: |
7，16 |
Printing Font Size: |
150u,200u |
Printing Height: |
10-60mm |
Printing Speed: |
0.5-60m/min |
One Printing: |
1-2 Lines |
Store Information: |
200 Items |
Trigger Mode: |
Photoelectric Sensor Trigger |
Printing Variables: |
Time Variables, Counters, Segmented Counting |
Printing Material: |
Available In Permeable Or Non-permeable Materials |
Printable Information: |
Numbers, Letters, Chinese, Image LOGO, Special Symbols |
Printing Distance: |
5-50mm From The Surface Of The Object To Be Printed |
Ink Performance: |
Water-based, Quick-drying |
Ink Color: |
Black, Red, Blue, Green, Yellow, White, Invisible Red Available |
Status Display: |
The Red Indicator Light Is On When Printing |
Air Pressure: |
External Air Pump Pressure 0.035Mpa |
Software Function: |
Real-time Date Clock, Print Batch, Count, Shift, Font Upside Down, Left And Right Flip |
Operating Temperature: |
-5℃-40℃ |
Machine Appearance: |
Injection Molding Of The Whole Machine, Wear-resistant And Durable |
Product Name: |
DOD Assembly Line Intelligent Large Font Inkjet Printer |
Bitmap Font: |
16 Point, 14 Point, 12 Point, 8 Point, 7 Point |
Number Of Nozzles: |
7，16 |
Printing Font Size: |
150u,200u |
Printing Height: |
10-60mm |
Printing Speed: |
0.5-60m/min |
One Printing: |
1-2 Lines |
Store Information: |
200 Items |
Trigger Mode: |
Photoelectric Sensor Trigger |
Printing Variables: |
Time Variables, Counters, Segmented Counting |
Printing Material: |
Available In Permeable Or Non-permeable Materials |
Printable Information: |
Numbers, Letters, Chinese, Image LOGO, Special Symbols |
Printing Distance: |
5-50mm From The Surface Of The Object To Be Printed |
Ink Performance: |
Water-based, Quick-drying |
Ink Color: |
Black, Red, Blue, Green, Yellow, White, Invisible Red Available |
Status Display: |
The Red Indicator Light Is On When Printing |
Air Pressure: |
External Air Pump Pressure 0.035Mpa |
Software Function: |
Real-time Date Clock, Print Batch, Count, Shift, Font Upside Down, Left And Right Flip |
Operating Temperature: |
-5℃-40℃ |
Machine Appearance: |
Injection Molding Of The Whole Machine, Wear-resistant And Durable |
Online Dod Large Character Inkjet Printer
Describe
DOD assembly line intelligent large font inkjet printer, can print numbers, letters, Chinese, image logos, special symbols, barcodes, QR codes, etc., with multiple colors to choose from, black, white, red, yellow, blue, green, data transmission through WiFi, visual operation, built-in multiple languages and fonts, simple operation, stable performance, widely used in various industries, such as construction, logistics, food, building materials, etc., easy maintenance. When shutting down each time, please use different methods according to the expected shutdown time, such as:If the machine time is within 2 days, it can be turned off directly without wiping the nozzle. If the machine is shut down for 2-10 days, use Clean the nozzle with specialized cleaning solution. If the downtime exceeds ten days, please fill the entire ink circuit with cleaning solution.
Features
★Intelligent data transmission method
Wifi transmission, visual operation through APP software, one-click transmission, one-click printing
★Rich ink selections
Ketone-based, water-based, and other color inks (black, white, yellow, blue, red, green), using 1L, 20L ink supply
★Power supply
Power supply voltage: AC220V/50HZ
★Professional and innovative technology
In response to market demand, innovative inkjet coding technology, stable nozzles, and built-in multiple languages and fonts
★Can scan barcodes and QR codes for printing
★Successfully applied industries
L3 can be used in logistics and express delivery, construction and building materials, metal, chemical cement, petroleum, wood, food and other industries
Specification
| Nozzle and print height | |
| Number of nozzles | 7,16 |
| Nozzle hole diameter | 150u,200u |
| Printing height | 10-60mm |
| Printing information parameters | |
| One printing | 1-2 lines |
| Bitmap font | 16 point, 14 point, 12 point, 10 point,, 8 point,, 7 point |
| Software function | Real-time date clock, print batch, count, shift, font upside down, left and right flip |
| information | Numbers, letters, Chinese, image LOGO, special symbols |
| Printing variables | Time variables, counters, segmented counting |
| Store information | 200 items |
| Ink and cartridges | |
| Ink performance | Water-based, quick-drying |
| Ink color | Black, red, blue, green, yellow, white, invisible red available |
| Printing speed and direction | |
| printing speed | 0.5-60m/min |
| Trigger mode | Photoelectric sensor trigger |
| Printing distance | 5-50mm from the surface of the object to be printed |
| Printing material | Available in permeable or non-permeable materials |
| Status Display | The red indicator light is on when printing |
| physical properties | |
| Air pressure | External air pump pressure 0.035Mpa |
| Operating temperature | -5℃-40℃ |
| Machine appearance | Injection molding of the whole machine, wear-resistant and durable |
